| 起源の場所: | 中国 |
|---|---|
| ブランド名: | EVERSUN |
| 証明: | ISO,CE |
| モデル番号: | SYH |
| 最小注文数量: | 1セット |
| 価格: | 交渉可能 |
| パッケージの詳細: | 標準的な輸出用木製ケース |
| 受渡し時間: | 7～15営業日以内 |
| 支払条件: | L/C、D/A、D/P、T/T、マネーグラム、ウェスタンユニオン |
| 供給の能力: | 5000セット/年 |
| クリーニング: | 清掃 に 容易 な | 安全機能: | 非常停止ボタン |
|---|---|---|---|
| コントロール: | 作業員に制御しやすい | スピード: | 調整可能な |
| モデル: | 3D-100 | 材料: | ステンレス鋼 |
| 応用: | 薬剤,化学,食品など | タイプ: | 立場のミキサー |
| 放電する: | 退院したけど残骸はない | ハンドル: | 操作しやすい |
| 混合方法: | タンブリングと回転 | 研磨: | 素晴らしい鏡面研磨、デッドコーナーなし |
| ハイライト: | Stainless Steel Three-dimensional Mixer,Adjustable Speed 3D Mixer,Easy Cleaning Three Dimensional Mixer |
||
Product Description
The 3D mixer is an efficient industrial mixing equipment, widely used in the fields of food, chemical engineering, new materials, and scientific research. It achieves multi-dimensional compound motion of the container within the space, allowing the materials to achieve full convection and diffusion without the interference of centrifugal force. This completely eliminates the mixing dead zones and stratification phenomena. This equipment is usually made of high-quality metal materials, with smooth inner walls and no residues. It is not only easy to clean and maintain, but also can achieve extremely precise uniform mixing while ensuring the integrity of the physical form of the materials. It is an ideal efficient processing solution for modern refined production.
Working Principle
The 3D mixer is an efficient mixing device that utilizes the principle of multi-dimensional compound motion in space. By driving the mixing cylinder to simultaneously perform translation, rotation and rolling, the material generates intense circumferential, radial and axial convection and diffusion within the cylinder. This unique motion method completely eliminates the mixing dead zones and the segregation caused by centrifugal force, and can achieve extremely high uniformity of mixing in a very short time. It is particularly suitable for precise processing scenarios where strict requirements are placed on mixing accuracy and material integrity.
Characteristics & Advantages
1. High uniformity of mixture, no dead corners: The three-dimensional composite motion enables the materials to flow in all directions, eliminating dead corners and stratification, ensuring extremely high mixing accuracy.
2. Large loading coefficient, high efficiency: High utilization rate of effective volume, large single processing capacity, fast mixing speed, significantly shortening the production cycle.
3. Strong adaptability of materials, no damage: Gentle rolling mixing, without destroying the material shape, especially suitable for fragile and heat-sensitive materials.
4. High cleanliness, easy cleaning: The inner wall of stainless steel is smooth without residues, closed operation prevents contamination, and it is convenient for cleaning and maintenance.
5. Smooth operation, energy-saving and environmentally friendly: Reasonable structural design, low noise, small vibration, low energy consumption per unit output.
Product Parameter
| Model | SYH-5 | SYH-15 | SYH-50 | SYH-100 | SYH-200 | SYH-400 | SYH-600 | SYH-800 | SYH-10 00 |
SYH-12 00 |
SYH-15 00 |
SYH-20 00 |
| Total volume(L) | 5 | 15 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1500 | 2000 |
| Effective volume(L) | 4.5 | 13.5 | 45 | 90 | 180 | 360 | 540 | 720 | 900 | 1080 | 1350 | 1800 |
| Maximum loading weight (kg) |
1.5-2.7 | 4-8.1 | 15-27 | 30-54 | 50-108 | 100-216 | 150-324 | 200-432 | 250-540 | 366-648 | 400-810 | 500-1080 |
| Spindle speed (r/min) |
0-20 | 0-20 | 0-20 | 0-20 | 0-15 | 0-15 | 0-13 | 0-10 | 0-10 | 0-9 | 0-9 | 0-8 |
| Motor power(kw) | 0.25 | 0.37 | 1.1 | 1.5 | 2.5 | 4 | 5.5 | 7.5 | 11 | 11 | 15 | 18.5 |
| Overall dimension (mm) |
600* 1000* 1000 |
800* 1200* 1000 |
1150* 1400* 1000 |
1250* 1800* 1550 |
1450* 2000* 1550 |
1650* 2200* 1550 |
1850* 2500* 1750 |
2100* 2650* 2000 |
2150* 2800* 2100 |
2000* 3000* 2260 |
2300 *3200* 2500 |
2500* 3500* 2800 |
| Weight(kg) | 100 | 200 | 300 | 800 | 1200 | 1200 | 1500 | 1700 | 1800 | 2000 | 2400 | 3000 |
| More sizes can be customize | ||||||||||||
